General Specifications
• 16-character LCD display
• Windows® drivers: 2000, XP, Server 2003; Vista
• Bi-directional driver communication
• Two year printer warranty
• Two year ( unlimited passes) original printhead
warranty

Printing
• Color dye sublimation or monochrome thermal
transfer printing
• 144 cards per hour full color single-sided ( YMCKO)
( P330i) * *
• 692 cards per hour ( monochrome) * *
• 300 dpi ( 11.8 dots/ mm) print resolution
• Two year ( unlimited passes) original printhead
warranty
* * Based on average print count per card, under certain conditions.

Bar Codes
• Code 39, Code 128 B & C with & without check digit
• 2-of-5 & 2-of-5 Interleaved
• UPC-A, EAN 8 & EAN 13
• PDF417 2-D bar code and other symbologies can be
printed via Windows drivers

Card Specifications
• Types: PVC, Composite, Adhesive backed
• Card width/ length: ISO CR-80-ISO 7810,
2.12" / 54 mm x 3.38" / 86 mm
• Magnetic Stripe— ISO 7811
• Smart Card contact and contactless
• Card thickness: 10 mil ( .25 mm) to 60 mil
( 1.524 mm) ( + / - 10% )
• Card feeder capacity: 100 cards ( 30 mil) or
220 cards ( 30 mil)
• Card output hopper capacity: 100 cards ( 30 mil)

Communications Interface
• USB 1.1 ( USB 2.0 compatible) cable included
• Optional Built-in 10/ 100 Ethernet

Ribbon Specifications
• i Series™ printers require the use of i Series
ribbons for full color printing ( P330i)
• YMCKO: 200 & 330 cards/ roll ( P330i)
• 1/ 2 Panel YMC Full KO: 450 cards/ roll ( P330i)
• KdO and KrO: 500 cards/ roll ( P330i)
• Overlay varnishes: Clear and Hologram:
350 cards/ roll
• Monochrome: 1500 ( Black) & 1000 cards/ roll
• Monochrome colors: black, red, blue, green,
silver, gold, white and scratch-off grey
• For optimum printer performance use
genuine Zebra supplies

Mechanical
• Width: 18.2" / 462 mm
• Depth: 9.4" / 239 mm
• Height: 10.1" / 256 mm
• Weight: 15.5 lbs/ 7.0 kg

Electrical
• 100 ~ 240 Volts AC, 50 ~ 60 Hz ( auto switching)
• 20 MB image memory standard
• FCC Class A, CE, UL, CUL, and CCC approved

Environmental
• Operating Temperature: 60° F/ 15° C to 86° F/ 30° C
• Operating Humidity: 20% to 65% non-condensing
• Storage Temperature: 23° F/ -5° C to 158° F/ 70° C
• Storage Humidity: 20% to 70% non-condensing
• Ventilation: Free air

Options
• Built-in 10/ 100 Ethernet
• Gen 2 UHF RFID Encoder— ISO 18000-6C
• Smart card contact— ISO 7816 encoder
( 30 mil cards only)
• Smart card MIFARE® / DESFire® encoder
( 30 mil cards only)
• Smart card contact station ( 30 mil cards only)
• Magnetic encoder ( 30 mil cards only)
3 track HiCo/ LoCo
• High capacity feeder ( 220 cards
